SPECIFICATIONS

Nominal Pipe Capacity1/4"-2" (6mm-100mm) @ 36 RPM, 2-1/2"-4" (65mm-100mm) @ 12 RPM, 4"-6" (100mm-150mm) with 161 Geared Threader.

Bolt Capacity1/4"-2" (6mm-50mm).

Motor ControlReverse/Off/Forward, heavy-duty rotary-type and integral foot switch.

Gear BoxTwo-speed gear box 3:1 ratio.

ChuckHammer-type with replaceable rocker-action jaw inserts.

Rear Centering DeviceCam action.

Oiling PumpSelf-priming, gerotor-type, automatic-reversing, constant-fl ow.

OilingThrough die head

Model 1224 Threading Machine

FEATURES

  • The Model 1224 threads a wide range of pipe including black, galvanized and plastic-coated pipe, together with stainless steel, IMC and heavy-wall conduit, as well as rod up to 30 Rockwell C.
  • An induction motor helps minimize noise.
  • A special capacitor-start / capacitor-run motor allows the 1224 to thread a full range of material where voltage drop is experienced.
  • 1/4"-2" Universal Die Head; 2 1/2"-4" receding die head allows cutting of tapered or straight NPT/NPSM or BSPT/BSPP threads.
  • Constant and proper lubrication of dies and workpiece with through-head oiling.
