B-500 Transportable Pipe Beveller



The B-500 Transportable Pipe Beveller produces high quality bevels in less than two minutes* without flames or sparks. The compact design quickly mounts to pipe 4” and up with a maximum wall thickness of 1/2”, and creates consistent bevels in a single pass.

*Schedule 40 pipe with a diameter of 12” or less

FEATURES

Speed

  • Set-up And Bevel 12" Diameter Schedule 40 Pipe In Under 2 Minutes!
  • Pipe Is Cool To Touch Immediately Following Bevelling

Consistency

  • Accurate Bevel Angle Around Diameter Of The Pipe Allows For Optimal Number Of Cover Passes
  • Adjustable Land Width From 0" to 3/16" To Fit Welders’ Requirements
  • Produces A Machined Finish Due To 6 Replaceable Cutter Inserts Working Simultaneously

Simplicity

  • Fast To Set-up And Operate
  • Patent-Pending Clamp System Firmly Secures Tool To The Pipe
  • Speed Monitoring With LED Indicators For Optimal Cutter Performance
  • Spark Free Operation
